| Parameter | Units | CK5225×H/20 | CK5232×H/20 | CK5240×H/20 |
|---|---|---|---|---|
| Max.turning diameter | mm | 2500 | 3200 | 4000 |
| Table diameter | mm | 2250 | 2500 | 2830 |
| Max.height of workpiece | mm | 1600/2000 | 1600/2000 | 2000/2500 |
| Max.weight of workpiece | t | 20 | 20 | 20 |
| Max.torque of table | kn.m | 63 | 63 | 63 |
| Spindle speed range | r/min | 2-63 | 2-63 | 2-63 |
| Max. cutting force of vertical tool holder | kn | 30 | 35 | 35 |
| Range of tool feed | mm/min | 0.2-145 | 0.2-145 | 0.2-145 |
| Horizontal travel of vertical tool holder | mm | 1400 | 1750 | 2150 |
| Vertical tool holder slide travel | mm | 1000 | 1250 | 1250 |
| Tool holder rapid traverse | mm/min | 3500 | 3500 | 3500 |
| Tool shank size | mm | 40*50 | 40*50 | 40*50 |
| Main motor power | kw | 55 | 55 | 55 |
| Overall dimension(L*W*H) | cm | 540*470*480/520 | 610*480*520/570 | 690*510*640/690 |
| Weight(about) | t | 34/36 | 38/40 | 44/46 |
